Arcam
Lượt xem: 2449

Trong kho : Còn hàng

Bảo hành : 12 tháng

Giá bán : 30.000.000đ

In any amplifier, the signal path is at the mercy of anything that creates noise within the unit. Thus, we spare no expense in using only the most high-quality components, even if it means the cost of our power supplies overtaking that of everything else.

Read More

Liên hệ giá tốt nhất

SA10

In any amplifier, the signal path is at the mercy of anything that creates noise within the unit. Thus, we spare no expense in using only the most high-quality components, even if it means the cost of our power supplies overtaking that of everything else.

The result, of course, is worth every penny.

A singer’s sharp intake of breath before hitting the chorus, a guitarist’s fingers sliding against the strings – it’s those seemingly minor details that can bring music to life. Fish out one of your all-time favourite albums and play it through a Bluetooth speaker, and guess what? Its sounds like a Bluetooth speaker. Play it through the SA10, and it’s as close to hearing the artist’s performance as you’re likely to get. There’s always joy in digging out an old recording you haven’t heard in years. With the HDA range, it’ll feel like hearing it forthe first time.



PRODUCT DETAILS

  • Extremely efficient class A/B amplification
  • 50W of power per channel
  • 5 analogue inputs including phono
  • 3 digital inputs
  • 32-bit DAC,Sabre ESS9016K2M
  • Full I/P control
  • Total harmonic distortion + noise = 0.003%

Specifications

Continue vermogensuitgang (0,5% THD), per kanaal
Beide kanalen, 8 Ω, 20 Hz-20 kHz 50W
Beide kanalen, 4 Ω, op 1 kHz 85W
Harmonische vervorming, 80% vermogen, 8 Ω op 1 kHz 0,003%
Analoge ingangen
Phono (MM) cartridge:
Ingangsgevoeligheid op 1 kHz 5mV
Ingangsimpedantie 47 kΩ + 100 pF
Frequentiebereik (zie RIAA kromme) 20Hz – 20kHz ± 1dB
Signaal/ruisverhouding (A-wtd) 50W, ref. 5mV invoer 80 dB
Overbelastingmarge, ref. 5mV op 1kHz 21dB
Lijningangen:
Nominale gevoeligheid 1V
Ingangsimpedantie 10 kΩ
Maximale ingang 6Vrms
Frequentiebereik 20Hz – 20kHz ± 0,2dB
Signaal/ruisverhouding (A-wtd) 50W, ref. 1V invoer 106 dB
Digitale ingangen
DAC ESS9016K2M
Frequentiebereik 20Hz - 20kHz ± 0,05dB
Totale harmonische vervorming + ruis 0,0007%
Signaal/ruisverhouding (A-wtd) 115dB
Ondersteunde samplesnelheden Optisch Coaxiaal
32kHz, 44,1kHz, 48kHz, 88,2kHz, 96kHz 32kHz, 44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz, 192kHz
Bitdiepte 16-bit – 24-bit
Voorversterkeruitgang
Nominaal uitgangsniveau 630mV
Uitgangsimpedantie 230 Ω
Hoofdtelefoonuitgang
Maximaal uitgangsniveau in 600 Ω 5Vrms
Uitgangsimpedantie 1 Ω
Belastingbereik 16Ω – 2kΩ
Algemeen
Netspanning 110–120V of 220–240V, 50–60Hz
Maximaal stroomverbruik 350W
Afmetingen B x H x D (inclusief voetstukken, bedieningsknop en luidsprekerklemmen) 433x87x310mm
Gewicht (netto) 8.4kg
Gewicht (bruto) 10.7kg
